General purpose grades
Grades / Special grades
MVR (300 °C/1.2 kg) 19 cm³/10 min; low viscosity; easy release; flame retardant; variable content of filler for high reflectance application; injection molding
Rheological properties
Property | Test Condition | Unit | Standard | typical Value | |
Melt volume-flow rate |
300 °C/ 1.2 kg
|
cm³/10 min | ISO 1133 |
19
|
Mechanical properties (23 °C/50 % r. h.)
Property | Test Condition | Unit | Standard | typical Value | |
C | Tensile modulus | 1 mm/min | MPa | ISO 527-1,-2 | 2500-2700 |
Yield stress
|
50 mm/min | MPa | ISO 527-1,-2 | 60 | |
Yield strain
|
50 mm/min | % | ISO 527-1,-2 | 5.5 | |
Nominal strain at break
|
50 mm/min | % | ISO 527-1,-2 | >50 | |
C |
Stress at break
|
50 mm/min | MPa | ISO 527-1,-2 | 50-60 |
C |
Stress at break
|
50 mm/min | % | ISO 527-1,-2 | 80-110 |
C |
Charpy impact strength
|
23 °C | kJ/m² |
ISO 178
|
N |
Izod notched impact strength
|
23 °C | kJ/m² | ISO 21305/based on ISO 180/A | 15(C) | |
C |
Puncture impact properties - maximum force
|
23 °C | N |
ISO 6603-2
|
4700-5100 |
C |
Puncture energy
|
23 °C | J |
ISO 6603-2
|
40-47 |
